The Fujitsu Airstage SET-ASTH09KNCA is a compact reverse-cycle wall-mounted air conditioner designed for bedrooms, home offices and other smaller rooms. It delivers 2.5kW rated cooling and 3.2kW rated heating, providing efficient year-round temperature control.
Featuring an award-winning indoor-unit design, quiet operation, R32 refrigerant and cooling performance at outdoor temperatures up to 50°C, the Comfort Series combines a modern appearance with dependable performance in Australian conditions.
Features
2.5kW rated cooling capacity
3.2kW rated heating capacity
Reverse-cycle heating and cooling
Compact, award-winning indoor-unit design
Suitable for smaller rooms
Inverter-controlled operation
R32 refrigerant with lower global-warming potential
Cooling operation in outdoor temperatures up to 50°C
Precise 0.5°C temperature adjustment
Powerful Mode for rapid heating or cooling
Economy Mode for reduced compressor power consumption
Super Quiet indoor fan operation
Automatic changeover between heating and cooling
Automatic restart following a temporary power interruption
Up-and-down automatic swing louvre
Sleep, program and on/off timers
Washable front panel
Filter-cleaning reminder
Blue Fin outdoor heat-exchanger protection
Demand Response Enabled Device terminal
Optional anywAiR Wi-Fi control
Indoor & Outdoor
| Specification | Details |
|---|
| Indoor Model | ASTH09KNCA |
| Indoor Dimensions | 270 × 784 × 224mm |
| Indoor Weight | 8kg |
| Outdoor Model | AOTH09KNCA |
| Outdoor Dimensions | 541 × 663 × 290mm |
| Outdoor Weight | 25kg |
| Pipe Sizes | 6.35mm liquid / 9.52mm gas |
| Refrigerant | R32 |
| Cooling Capacity | 2.5kW rated; 0.9–3.7kW operating range |
| Heating Capacity | 3.2kW rated; 0.9–4.8kW operating range |
| Air Flow | 175L/s on high fan, cooling and heating |
| Drain | 13.0mm ID / 15.0–16.8mm OD |
| Power Supply | 220–240V, single-phase, 50Hz |
| Max Current | 9.0A |
Performance Specifications
| Specification | Cooling | Heating |
|---|
| Rated Capacity | 2.5kW | 3.2kW |
| Capacity Range | 0.9–3.7kW | 0.9–4.8kW |
| Rated Input Power | 0.59kW | 0.77kW |
| Input-Power Range | 0.25–1.14kW | 0.25–1.14kW |
| Running Current | 3.0A | 3.8A |
| EER / COP | 4.24 | 4.16 |
| Indoor Sound Pressure – High | 46dBA | 46dBA |
| Indoor Sound Pressure – Quiet | 22dBA | 27dBA |
| Outdoor Sound Pressure | 49dBA | 51dBA |
Additional Specifications
| Specification | Details |
|---|
| Set Code | SET-ASTH09KNCA |
| System Type | Reverse-cycle inverter split system |
| Recommended Breaker | 15A |
| Moisture Removal | 1.0L/h |
| Outdoor Sound Power Level | 62dBA |
| Maximum Pipe Length | 20m |
| Factory-Precharged Pipe Length | 15m |
| Maximum Height Difference | 15m |
| Cooling Operating Range | −10°C to 50°C |
| Heating Operating Range | −15°C to 24°C |
| Factory Refrigerant Charge | 550g |
| Cooling Star Rating – Hot/Average/Cold | 5.0 / 4.5 / 4.5 |
| Heating Star Rating – Hot/Average/Cold | 3.5 / 3.0 / 2.5 |
| TCSPF – Hot/Average/Cold | 6.535 / 6.114 / 6.476 |
| HSPF – Hot/Average/Cold | 5.235 / 4.625 / 4.005 |
Optional Controls and Accessories
| Accessory | Model Number | Details |
|---|
| anywAiR Technology Wi-Fi Adaptor II | UTY-NXT-BOX | Enables control through the free myanywAiR Next smartphone and tablet application |
| Wi-Fi Adaptor Connection Cable | UTY-NXT-CAB | Required with the UTY-NXT-BOX for compatible Comfort Series installations |
| Kagami Wired Remote Controller | UTY-RVRY | Optional premium wired controller; optional communication kit required |
| LCD Touch Panel Controller | UTY-RNRYT5 | Optional touch-panel controller; optional communication kit required |
| LCD Simple Controller with Operating Mode | UTY-RSRYT | Simplified wired control with operating-mode selection; optional communication kit required |
| LCD Simple Controller without Operating Mode | UTY-RHRYT | Simplified wired control without operating-mode selection; optional communication kit required |
Wi-Fi Control
When fitted with the optional UTY-NXT-BOX Wi-Fi Adaptor II and UTY-NXT-CAB connection cable, the system can be controlled through Fujitsu’s free myanywAiR Next application using a compatible smartphone or tablet.
A licensed installer and the appropriate connection cable are required to install the Wi-Fi adaptor.
Typical Applications
Important Information
This set includes the ASTH09KNCA indoor unit and AOTH09KNCA outdoor unit.
Optional controllers and Wi-Fi components are sold separately.
Optional wired controllers require the appropriate Fujitsu communication kit.
Available functions may vary according to the installed controller and system configuration.
Installation must be completed by a suitably qualified and licensed air-conditioning installer.
Capacity suitability should be confirmed through an appropriate room heat-load assessment.
Source: Fujitsu Airstage Comfort Range Australian Brochure – January 2025.
