Schneider Electric A9C20732 Acti9 iCT 25A 2NO 230–240V Contactor
The Schneider Electric A9C20732 is an Acti9 iCT modular contactor designed for remote switching of motor, heating and lighting circuits. With a 25A AC-7A rating, 2 normally open poles and a 230–240V AC 50Hz control circuit, it is suited to residential and small commercial control applications.
Key Features
Acti9 iCT modular contactor
25A rated operational current at AC-7A
8.5A rated operational current at AC-7B
2 pole, 2 normally open contact configuration
230–240V AC 50Hz control circuit
Remote control operation
Clip-on mounting for 35mm DIN rail
Action indicator for local signalling
IP20 protection rating
Suitable for motor, heating and lighting applications
Specifications
| Specification | Details |
|---|
| Product Code | A9C20732 |
| Brand | Schneider Electric |
| Range | Acti9 |
| Product Name | Acti9 iCT |
| Product Type | Modular Contactor |
| Poles | 2P |
| Contact Composition | 2 NO |
| Rated Operational Current | 25A AC-7A / 8.5A AC-7B |
| Control Circuit Voltage | 230–240V AC 50Hz |
| Rated Operational Voltage | 250V AC 50Hz |
| Rated Insulation Voltage | 500V AC |
| Impulse Withstand Voltage | 4kV |
| Mounting | 35mm DIN rail |
| Width | 18mm |
| Height | 81mm |
| Depth | 68.5mm |
| Protection Rating | IP20 |
| Standard | IEC/EN 61095 |
| Warranty Listed by Schneider | 18 months |
Applications
Lighting control
Heating control
Small motor switching
Residential electrical boards
Small commercial control panels
HVAC-R auxiliary control circuits
Safety & Documentation
Install only by licensed electricians. Confirm control voltage, load type, rated current, protection device coordination, enclosure rating and Schneider Electric installation documentation before installation.
The A9C20732 is a compact Acti9 iCT contactor for reliable DIN rail switching of lighting, heating and motor control loads.
