11/8 PRESS 45 ELBOW (5 PACK)


The NIBCO® PressACR copper 45-degree elbow features an inboard bead and gray HNBR O-ring. Simply applying pressure from a pressing tool tightens the O-ring onto the tube, ensuring a clean, robust seal in seconds with no flame, solder or flux. The elbow has press connections. The fitting provides a method of changing the pipeline direction by 45 degrees. This fitting is used when a longer sweep is required.

Toggle Overview information
  • Operating pressure 700 psi max
  • Temperature range -40°F to 250°F
  • Vacuum: 500mi
  • Approved Refrigerants: R1234yf, R1234ze, R125, R134a, R143a, R404A, R407A, R407C, R407F, R410A, R417A, R422D, R447A, R448A, R449A, R450A, R452A, R452B, R507, R513A, R718, R32, R290, R600, R600A, R407B, R407G, R407H, R421C, R422A, R422B, R422C, R427A, R434
  • Approved Oils: POE, PAG, MO, PAO, PVE and ABR456A
  • UL 207 Recognized to 700 PSI
  • Complies with: ISO 5149-2, ISO I4903 Helium leak test, ISO 14903 Thermal cycle test, ISO 14903 Fatigue test, ISO 14903 Freeze test, UL 109 vibration
PRODUCT MODELS
SizeDescriptionUPCNIBCO No.
1/4 in. O.D. x 1/4 in. O.D.PC9606-LT 1/4 OD PRESS 45 ELBOW039923418166904250RPC
5/16 in. O.D. x 5/16 in. O.D.PC9606-LT 5/16 OD PRESS 45 ELBOW039923418173904255RPC
3/8 in. O.D. x 3/8 in. O.D.PC9606-LT 3/8 OD PRESS 45 ELBOW039923418180904260RPC
1/2 in. O.D. x 1/2 in. O.D.PC9606-LT 1/2 OD PRESS 45 ELBOW039923418159904270RPC
5/8 in. O.D. x 5/8 in. O.D.PC9606-LT 5/8 OD PRESS 45 ELBOW039923413468904280RPC
3/4 in. O.D. x 3/4 in. ODPC9606-LT 3/4 OD PRESS 45 ELBOW039923413475904286RPC
7/8 in. OD x 7/8 in. ODPC9606-LT 7/8 OD PRESS 45 ELBOW039923413482904296RPC
1 in. OD x 1 in. ODPC9606-LT 1 OD PRESS 45 ELBOW039923431547904290RPC
1-1/8 in. O.D. x 1-1/8 in. O.D.PC9606-LT 1-1/8 OD PRESS 45 ELBOW039923413499904300RPC
1-3/8 in. OD x 1-3/8 in. ODPC9606-LT 1-3/8 OD PRESS 45 ELBOW039923413505904310RPC
1-5/8 in. OD x 1-5/8 in. ODPC9606-LT 1-5/8 OD PRESS 45 ELBOW0399234442409043200RPC
2-1/8 in. OD x 2-1/8 in. ODPC9606-LT 2-1/8 OD PRESS 45 ELBOW0399234445239043305RPC
Add to Quote
Price

Internal Reference: NC-45E1/18
