The NIBCO® PressACR wrot copper tee features an inboard bead and gray HNBR O-ring. Simply applying pressure from a pressing tool tightens the O-ring onto the tube, ensuring a clean, robust seal in seconds with no flame, solder or flux. The tee has press connections and allows for a connection to be made in a continuous pipeline and branch out to a different direction.
- Operating pressure 700 psi max
- Temperature range -40°F to 250°F
- Vacuum: 500mi
- Approved Refrigerants: R1234yf, R1234ze, R125, R134a, R143a, R404A, R407A, R407C, R407F, R410A, R417A, R422D, R447A, R448A, R449A, R450A, R452A, R452B, R507, R513A, R718, R32, R290, R600, R600A, R407B, R407G, R407H, R421C, R422A, R422B, R422C, R427A, R434
- Approved Oils: POE, PAG, MO, PAO, PVE and ABR456A
- UL 207 Recognized to 700 PSI
- Complies with: ISO 5149-2, ISO I4903 Helium leak test, ISO 14903 Thermal cycle test, ISO 14903 Fatigue test, ISO 14903 Freeze test, UL 109 vibration
- PressACR® is a trademark of NIBCO INC.
Product Models
| Size | Description | UPC | NIBCO No. |
|---|
| 1/4 in. O.D. x 1/4 in. O.D. x 1/4 in. O.D. | PC9611 1/4 OD PRESS TEE | 039923418203 | 909555RPC |
| 5/16 in. O.D. x 5/16 in. O.D. x 5/16 in. O.D. | PC9611 5/16 OD PRESS TEE | 039923418227 | 909575RPC |
| 3/8 in. O.D. x 3/8 in. O.D. x 3/8 in. O.D. | PC9611 3/8 OD PRESS TEE | 039923418210 | 909600RPC |
| 1/2 in. O.D. x 1/2 in. O.D. x 1/2 in. OD | PC9611 1/2 OD PRESS TEE | 039923418197 | 909650RPC |
| 5/8 in. O.D. x 5/8 in. O.D. x 5/8 in. OD | PC9611 5/8 OD PRESS TEE | 039923413512 | 909720RPC |
| 3/4 in. O.D. x 3/4 in. OD x 3/4 in. OD | PC9611 3/4 OD PRESS TEE | 039923413529 | 909780RPC |
| 7/8 in. OD x 7/8 in. OD x 7/8 in. OD | PC9611 7/8 OD PRESS TEE | 039923413536 | 909840RPC |
| 1 in. OD x 1 in. OD x 1 in. OD | PC9611 1 OD PRESS TEE | 039923431554 | 909845RPC |
| 1-1/8 in. O.D. x 1-1/8 in. O.D. x 1-1/8 in. O.D. | PC9611 1-1/8 OD PRESS TEE | 039923413543 | 909930RPC |
| 1-3/8 in. OD x 1-3/8 in. OD x 1-3/8 in. OD | PC9611 1-3/8 OD PRESS TEE | 039923413550 | 910005RPC |
| 1-5/8 in. OD x 1-5/8 in. OD x 1-5/8 in. OD | PC9611 1-5/8 OD PRESS TEE | 039923444257 | 9101150RPC |
| 2-1/8 in. OD x 2-1/8 in. OD x 2-1/8 in. OD | PC9611 2-1/8 OD PRESS TEE | 039923444530 | 9102600RPC |
