Blauberg BLATURBO150ECTW Turbo EC 150mm Inline Mixed Flow Fan
The Blauberg BLATURBO150ECTW is best matched to the Blauberg Turbo EC 150 inline mixed-flow fan platform. It is designed for efficient ducted ventilation in residential, commercial and light industrial applications where strong airflow through 150mm round ductwork is required.
Using an energy-saving EC motor, the Turbo EC 150 provides airflow up to 600m³/h, with a compact inline body suitable for duct-mounted supply or exhaust ventilation systems.
Key Features
150mm inline mixed-flow fan
Turbo EC 150 fan platform
Energy-saving EC motor
Suitable for 150mm round duct systems
1~230V 50/60Hz supply
55W rated power
600m³/h maximum airflow
46 dB(A) sound pressure level at 3m
IPX4 ingress protection rating
Plastic casing
Mixed-flow impeller design
Suitable for installation in any position
Suitable for transported air temperatures from -25°C to +55°C
Designed for supply and exhaust ducted ventilation applications
Specifications
| Specification | Details |
|---|
| Product Code | BLATURBO150ECTW |
| Closest Blauberg Source Model | Turbo EC 150 / BLATURBOEC150 |
| Brand | Blauberg |
| Product Type | Inline Mixed Flow Fan |
| Duct Size | 150mm |
| Voltage | 1~230V |
| Frequency | 50/60Hz |
| Rated Power | 55W |
| Unit Current | 0.48A |
| Maximum Airflow | 600m³/h |
| Sound Pressure Level | 46 dB(A) at 3m |
| Motor Type | EC |
| Impeller Type | Mixed-flow |
| Casing Material | Plastic |
| Ingress Protection Rating | IPX4 |
| Weight | 2.95kg |
| Transported Air Temperature | -25°C to +55°C |
| Installation Position | Any position |
| Application | Supply and exhaust ducted ventilation |
| Source Note | Exact BLATURBO150ECTW page not found; specifications are from Blauberg Turbo EC 150 source data |
Applications
Bathroom exhaust ventilation
Laundry ventilation
Utility room ventilation
Residential ducted exhaust systems
Light commercial ventilation
Air transfer systems
Supply or exhaust ventilation through 150mm round duct
Ventilation upgrades requiring efficient EC motor operation
Inline fan replacement where 150mm sizing and performance match the installation
Safety & Documentation
Install only by licensed electricians or qualified ventilation technicians. Confirm duct size, airflow requirement, static pressure, controller compatibility, mounting location, electrical supply, condensation management and service access before installation.
Because the exact BLATURBO150ECTW code was not verified on the public Blauberg source, confirm whether the TW suffix refers to a timer, controller, plug/lead or other accessory configuration before final supply.
The Blauberg BLATURBO150ECTW is best treated as a 150mm Turbo EC inline mixed-flow fan reference for efficient ducted ventilation where EC motor performance and compact inline installation are required.
