HV1 Fieldpiece 3/8" Vacuum Hose
The Fieldpiece HV1 is a premium 3/8" vacuum-rated recovery hose designed for rapid evacuation of air conditioning and refrigeration systems. With 3/8" x 3/8" fittings, it connects directly to compatible Fieldpiece vacuum pumps and Fieldpiece SM380VINT / SM480VINT digital manifolds, helping technicians pull vacuum faster with reduced flow restriction. Fieldpiece Australia
Built for professional HVAC-R field use, the HV1 features rugged full-ring triple crimp construction, A2L compatibility and a permeation barrier that meets SAE J2196. Fieldpiece’s hose flyer also lists the HV1 as a 3/8" vacuum hose with 3/8" I.D. for rapid evacuation and four-layer construction. Fieldpiece Australia
Key Features
- Premium vacuum-rated hose
- Designed for rapid evacuation
- 3/8" x 3/8" fittings
- 3/8" internal diameter for improved evacuation flow
- A2L compatible
- Rugged full-ring triple crimp construction
- Four-layer hose construction
- Permeation barrier meets SAE J2196
- Suitable for refrigeration and air conditioning systems
- Compatible with Fieldpiece vacuum pumps and selected Fieldpiece digital manifolds
Specifications
| Specification | Details |
|---|
| Product Code | HV1 |
| Brand | Fieldpiece |
| Product Type | Vacuum / Recovery Hose |
| Fitting Size | 3/8" x 3/8" |
| Hose Length | 5 ft / 1.5 m |
| Internal Diameter | 3/8" |
| Working Pressure | 800 psi |
| Burst Pressure | 4000 psi |
| Compatibility | A2L compatible |
| Barrier Standard | SAE J2196 |
| Application | Evacuation and recovery |
Applications
- HVAC-R system evacuation
- Refrigeration service work
- Air conditioning installation
- Vacuum pump connection
- Digital manifold connection
- Recovery and evacuation tasks
- Commissioning and maintenance work
The Fieldpiece HV1 3/8" Vacuum Hose is a strong choice for HVAC-R technicians who need a durable, high-flow hose for faster evacuation and reliable vacuum performance on air conditioning and refrigeration systems.
