Danfoss / Secop FR6CL Hermetic Refrigeration Compressor – Single Phase
The FR6CL is a hermetic reciprocating compressor for low and medium temperature refrigeration using R404A or R507. Operating on a 220–240 V, 50 Hz single-phase supply, it features a capacitor-start induction-run motor and polyolester oil.
Technical Specifications
| Specification | Details |
|---|
| Model | FR6CL |
| Manufacturer code | 103U2670 |
| Compressor type | Hermetic reciprocating |
| Application | Low / medium back pressure (LBP/MBP) |
| Refrigerants | R404A / R507 |
| Power supply | 220–240 V / single phase / 50 Hz |
| Motor type | CSIR |
| Displacement | 6.23 cm³ |
| Suction connection | 8.2 mm internal diameter |
| Discharge connection | 6.2 mm internal diameter |
| Process connection | 6.2 mm internal diameter |
| Connection material | Copper-plated steel |
| Oil type | Polyolester (POE) |
| Oil charge | 0.45 L |
| Locked rotor current | 8.2 A, measured after 4 seconds |
| Overall height | 196 mm |
| Weight | 10.5 kg, excluding electrical equipment |
| Evaporating temperature range | −45°C to −5°C |
| Compressor cooling | Fan cooling at 3.0 m/s required |
Selection note: Specifications apply to FR6CL code 103U2670. Confirm the original compressor code, operating conditions and starting equipment when selecting a replacement.
Manufacturer source:
Secop FR6CL technical datasheet – 103U2670
