Secop Compressor R404A HBP 15.28 cm³ - SC15DL
The Secop SC15DL is a hermetic reciprocating compressor for high-back-pressure R404A refrigeration. Designed for 220–240 V, single-phase, 50 Hz operation, it features a 15.28 cm³ displacement and a high starting torque motor.
Technical Specifications
| Specification | Details |
|---|
| Model | SC15DL |
| OEM compressor code | 104L2866 |
| Compressor type | Hermetic reciprocating |
| Application | High back pressure (HBP) |
| Refrigerant for listed performance | R404A |
| Power supply | 220–240 V / Single phase / 50 Hz |
| Displacement | 15.28 cm³ |
| Motor type | CSCR – capacitor start, capacitor run |
| Starting torque | High starting torque (HST) |
| Suction connection internal diameter | 10.11–10.29 mm |
| Discharge connection internal diameter | 6.11–6.29 mm |
| Connection material | Copper |
| Oil type / charge | Polyolester / 0.550 L |
| Housing dimensions (L × W × H) | 218 × 151 × 219 mm |
| Length with electrical cover | 255 mm |
| Compressor weight | 13.5 kg |
Example Performance – R404A, 50 Hz
EN12900 HBP conditions: +5°C evaporating temperature, 50°C condensing temperature, 20°C return-gas temperature and 50°C liquid temperature; fan cooling at 3 m/s.
| Performance | Details |
|---|
| Cooling capacity | 1,847.7 W @ +5°C evaporating / 50°C condensing |
| Power input | 924.6 W |
| Running current at test conditions | 4.77 A at 220 V |
| Performance basis | OEM published data for code 104L2866 |
Manufacturer source:
Secop SC15DL – Technical specifications, performance and dimensional drawing
