Secop SC18CL Hermetic Reciprocating Compressor – Single Phase
The Secop SC18CL is a hermetic reciprocating compressor for low- and medium-back-pressure R404A refrigeration. It features a 17.69 cm³ displacement and capacitor-start, capacitor-run motor.
Technical Specifications
| Specification | Details |
|---|
| Model | SC18CL |
| Single-pack / compressor code | 195B4022 / 104L2123 |
| Compressor type | Hermetic reciprocating |
| Application | LBP / MBP within OEM envelope |
| Refrigerant for listed performance | R404A |
| Power supply | 220–240 V / Single phase / 50 Hz |
| Displacement | 17.69 cm³ |
| Motor / starting torque | CSCR / HST |
| Suction / discharge internal diameter | 10.11–10.29 / 6.11–6.29 mm |
| Oil charge | 0.601 L, polyolester |
| Housing dimensions (L × W × H) | 218 × 151 × 219 mm |
| Length with electrical cover | 255 mm |
| Compressor weight | 13.8 kg |
Example Performance – R404A, 50 Hz
EN12900 LBP: −35°C evaporating, 40°C condensing, 20°C return gas and 40°C liquid; fan cooling at 3 m/s.
| Performance | Details |
|---|
| Cooling capacity | 436.2 W @ −35°C / 40°C |
| Power input | 451 W |
| Running current | 3.01 A at 220 V |
Manufacturer source:
Secop SC18CL single-pack contents, technical data and dimensions
