Appion MegaFlow Vacuum Rated 5/16" Valve Core Removal Tool

Appion MegaFlow™ 5/16" Valve Core Removal Tool – MGAVCR

The Appion MGAVCR is a vacuum-rated valve core removal tool designed for 5/16" ductless and mini-split service ports. It allows technicians to remove restrictive valve cores during evacuation and refrigerant recovery, increasing flow through the access port and helping reduce evacuation and recovery times.

The MGAVCR uses a 5/16" female flare system connection to 1/4" male flare service connection, making it suitable for high-pressure ductless systems while retaining compatibility with standard 1/4" service hoses.

Features

• Designed for 5/16" ductless system service ports

• Removes restrictive Schrader valve cores during evacuation and recovery

• 5/16" Female Flare × 1/4" Male Flare

• 1/4" side port for service gauges

• Vacuum rated to 20 microns

• 800 PSI working pressure

• 4,000 PSI burst pressure

• Suitable for high-pressure refrigerants including R410A

• Adjustable valve-core gripping tip

• Magnetic base helps retain the stem during service

• Double O-ring sealed ball valve

• Serviceable with genuine Appion repair kits and replacement seals

Technical Specifications

Service & Replacement Parts

Appion specifically lists KTMV40 and KTMV25 as repair parts for the MGAVCT/MGAVCR valve core removal tool range.

The MGAVCR is particularly useful on ductless and mini-split systems where the factory service connection is 5/16", allowing the valve core to be removed while maintaining a high-flow 1/4" connection to evacuation and recovery equipment.

Manufacturer sources:

Appion MGAVCR – 5/16" Valve Core Removal Tool

Appion Valve Core Removal Tool Parts & Accessories Catalogue
